You might have read my article about plugging Wasm into Kafka Connect, but I wanted to revisit this from a different angle: what if instead of consuming data from a topic and manipulating such data on the client-side, we intercepted data as it lands on the Kafka broker?
But first of all, is it possible to extend the Kafka broker at all?
Well, yes and no. There are indeed some predefined hooks where we can plug custom Java code; in particular, there are places where you can plug your custom Java policy to validate pieces of data; but, at this time, these extension mechanisms do not deal with records.
The Kafka broker has supported custom user-defined code since at least version 0.10.0 with the interface CreateTopicPolicy**, ** which essentially amounts to implementing one method:
void validate(CreateTopicPolicy.RequestMetadata requestMetadata)
throws PolicyViolationException
This policy intercepts all the topic creation requests performed by an admin, injecting custom validation logic. In other words, the code you plug here will be executed every time someone invokes the standard utility kafka-topic.sh to create a new topic.
kafka-topics.sh --topic my-new-topic --create
Users define their own policy by implementing the CreateTopicPolicy interface, then they can package their implementation as a jar, and finally, provided that that jar will be available on the classpath at run-time, they can specify the class name using the broker config property create.topic.policy.class.name.
This is the perfect spot to plug the Chicory Extism SDK: Chicory is just plain, simple Java, but with a twist that proves essential when you are hosting user-defined code: sandboxing and guaranteed interruptability. This is what we will show in this blog post.
That’s all fine and dandy, but what about records? 🔗
In the past, there were a number of attempts to support record validation or transformation in the broker, but none landed on the trunk. For instance, in the order in which they were proposed:
- KIP-686: API to ensure Records policy on the broker
- KIP-729: Custom validation of records on the broker prior to log append
- KIP-905: Broker interceptors
- KIP-940: Broker extension point for validating record contents at produce time
In many cases, the proponents eventually did not follow through with their idea. One key issue is that supporting this kind of extension means running user-defined code on one of the hottest paths in the broker.
Not only is this controversial, but it is also highly risky because user-defined Java code might fail, go haywire, and, depending on how the code was written, even be hard to interrupt abruptly.
But the same is not true for Chicory. A Chicory runtime can be always interrupted.
So, in the next post of this series, we will walk you through a PoC where we patch the Kafka broker and expose a new interface in the style of CreateTopicPolicy. We will then implement this interface using Chicory to support interruptible, sandboxed data transforms. The new ProduceRequestInterceptor will, again, expose essentially one method:
RecordBatch intercept(RecordBatch batch)
throws ProduceRequestInterceptorException;
In practice, the basic design principles for our patch will be the same as those for CreateTopicPolicy (or any other Java extension point that is *already * present in Kafka). And, when we will plug Wasm support, we will follow the same pattern that we will detail in this blog post for CreateTopicPolicy.
Consider this as your way to get your feet wet.
Nice interface, it would be a shame if someone plugged some Wasm in it 🔗
So, let’s start simple. In this blog post we will implement the CreateTopicPolicy interface with Chicory, we will plug a Wasm module, and implement one such policy using Wasm and Go.
We will also show that even a malicious payload can be given a timeout and killed abruptly at any time.
CreateTopicPolicy implements the Configurable interface, which means you can also implement a method to configure your policy. This method will be passed the config properties of the broker. It is safe to assume that this method will be invoked before any topic creation request is handled; so for all intents and purposes, this may act as our initializer.
For instance, we could look for the path of Wasm binary at create.topic.policy.wasm.path and instantiate it. If you have read the previous blog post, you will notice a pattern.
public class WasmCreateTopicPolicyHandler implements CreateTopicPolicy {
private WasmCreateTopicPolicy policy;
@Override
public void configure(Map<String, ?> configs) {
// Get the config policy
String wasmPath = configs.get("create.topic.policy.wasm.path").toString();
try {
// Read our wasm file and instantiate a Manifest.
Path path = Path.of(wasmPath);
FileInputStream inputStream = new FileInputStream(wasmPath);
var manifest = new WasmTopicPolicyManifest(
inputStream, path.getFileName().toString(), Map.of());
// set the policy
this.policy = WasmCreateTopicPolicy.fromManifest(manifest);
} catch (IOException e) {
throw new ConfigException("Invalid Wasm binary", e);
}
}
@Override
public void validate(RequestMetadata requestMetadata) throws PolicyViolationException {
policy.validate(requestMetadata);
}
}
WasmCreateTopicPolicy is, like in the article, just a wrapper around an Extism plugin, exposing the validate method.
Alright, that’s all we need to get started. Now let’s define our validation extension point.
💡 For simplicity, in this example, instead of calling into the XTP service, we assume the plugin is available somewhere on disk, but the same loading strategy we demonstrated in the previous article could be also applied here, potentially allowing you to reload strategies from the network and on the fly. Be mindful, however, that you might not want to clog your broker by repeatedly polling an HTTP service.
XTP? More like ex-tee-policy am I right 🔗
In this case, the XTP schema needs very little design. It’s just a matter of porting over the Java interface, including the RequestMetadata data structure:
exports:
validate:
input:
$ref: "#/components/schemas/RequestMetadata"
contentType: application/json
version: v1-draft
components:
schemas:
RequestMetadata:
properties:
topic:
type: string
description: the name of the topic to create
configs:
type: object
description: topic configs in the request, not including broker defaults
numPartitions:
type: integer
description: the number of partitions to create or null if replicaAssignments is not null.
replicationFactor:
type: integer
description: the number of replicas to create or null if replicaAssignments is not null
replicasAssignments:
type: object
description: a map from partition id to replica (broker) ids or null if numPartitions and replicationFactor are set instead.
We can now write our policy plugin with xtp plugin init. I named it create-topic-policy-example. Here’s my main.go:
package main
import (
"errors"
"strings"
)
func Validate(input RequestMetadata) error {
if strings.Contains(input.Topic, "__INVALID__") {
return errors.New("contained the magic keyword `__INVALID__`")
}
return nil
}
This simple plug-in intercepts all topic creation requests and rejects all those that contain the text __INVALID__. Build your plugin with xtp plugin build and then configure the broker with the newly created property to point to your wasm binary:
create.topic.policy.wasm.path=/path/to/create-topic-policy-example/dist/plugin.wasm
Start your Kafka broker, and if everything goes as planned, you can now try to create a topic with the magic string:
❯ bin/kafka-topics.sh --bootstrap-server localhost:9092 \
--topic my__INVALID__topic --create
Error while executing topic command : Wasm Policy rejected the topic
'my__INVALID__topic' with error 'Error evaluating function validate:
Topic rejected, contained the magic keyword '__INVALID__''
while all other topics will work as expected
❯ bin/kafka-topics.sh --bootstrap-server localhost:9092 \
--topic my-topic --create
Created topic my-topic.
There’s no trick here! The policy is evaluated by the broker, and the error is returned to the client.
Killing me softly 🔗
Now what if our policy goes rogue? Let’s modify our plug-in as follows:
func Validate(input RequestMetadata) error {
for {
// infinite loop
}
return nil
}
The Chicory runtime handles thread interruption requests, so execution can be safely interrupted at any time. Let’s modify our validate() routine with a timeout:
public void validate(RequestMetadata requestMetadata) throws PolicyViolationException {
try {
CompletableFuture
.runAsync(() -> this.policy.validate(requestMetadata))
.get(500, TimeUnit.MILLISECONDS);
} catch (InterruptedException | TimeoutException e) {
throw new PolicyViolationException(
"Policy evaluation exceeded the given time limit. " +
"Default to reject.", e);
} catch (ExecutionException e) {
// handle the execution exception and turn it into a PolicyViolationException
throw new PolicyViolationException(...);
}
}
Now the policy will be terminated after a maximum of 500 milliseconds.
❯ bin/kafka-topics.sh --bootstrap-server localhost:9092 --topic my_topic --create
Error while executing topic command : Policy evaluation exceeded the given time
limit. Default to reject.
Congrats! You just plugged Wasm in a Kafka broker!
💡 Rough around the edges. The example we have written is not thread-safe because it reuses a single Wasm instance against all requests. If multiple requests were to be served at the same time, we might corrupt the Wasm memory. You might want to create a pool of Wasm plug-ins and reuse them to serve distinct validation requests.
Conclusions 🔗
I hope you enjoyed this introduction to extending the Kafka broker with Chicory and Extism. In the next post, we will detail the delicate path where the Kafka broker handles incoming records.
Brace for some open-heart surgery on the core of Kafka!
