I am resurrecting my old “Wasm the Hard Way” series with a some fresh new content about a recent project I have been working on: porting the Chicory Wasm compiler to Android.
If you are interested in Wasm and Java, you might have heard about Chicory, a pure-Java Wasm runtime. Ever since I started working at Dylibso, I have been contributing to the project.
Extism is Dylibso’s family of open-source projects to develop and host WebAssembly (Wasm) plugins. Going forward, we believe the Chicory SDK is a solid foundation for running Wasm modules in Java applications, making it our default Wasm runtime for Extism on the Java platform. We’re putting our money where our mouth is: the mcpx4j library for running mcp.run servlets is built on top of the Chicory SDK.
At Dylibso, we have also been working on mcp.run, a platform for writing, sharing and evaluating secure, sandboxed MCP “servlets”. The secret sauce of course remains Wasm, as the foundations are still laid on Extism and our XTP plugin registry.
Because Chicory is written in Java, it can run on any platform that supports the Java language. In fact, it is pretty easy to run the Chicory interpreter on Android. But the Chicory runtime is not just an interpreter: it also includes a compiler that translates Wasm into Java bytecode!
Unfortunately, the Android platform does not run Java bytecode, but Dalvik bytecode (DEX files). The Android toolchain translates Java bytecode into Dalvik bytecode at build-time. Does that mean you can use the Chicory compiler to translate Wasm into Dalvik bytecode? Well, yes—but it heavily depends on your use case.
This blog post documents why and how we ported the Chicory compiler to Android, the challenges we faced, and how we solved them. We also document how we are now testing the Android backend of the Chicory compiler, which deviates from how Android apps are usually developed. Ever wondered how to run and debug code on Android without the overhead of the Android Instrumentation framework? Read on!
Porting Chicory to Android 🔗
As mentioned, the Chicory compiler can run at build-time or at run-time. The build-time flavor translates Wasm into Java bytecode and dumps the result into class files on disk. The run-time compiler loads this same bytecode dynamically, allowing you to load and run Wasm modules on-the-fly.
The interpreter is our reference implementation; as runtime maintainers, our key priority is keeping it easy to understand, debug and test. Development tends to move faster than the compiler: features are developed and tested first in the interpreter, then ported to the compiler as they stabilize. Therefore, the interpreter is meant to follow the spec rather strictly, not to be efficient. The compiler, on the other hand, is useful when you want to run Wasm modules with better performance.
The build-time compiler is the best pick when the Wasm modules you want to run are known at build-time. For instance, if a specific library has been ported to Wasm, you can convert it to Java bytecode and use it as plain Java code: this is the case for sqlite4j, a library that allows you to run SQLite databases in pure-Java.
On the other hand, you will reach for the run-time compiler when you want to run Wasm modules that are not known at build-time. This is where Wasm’s sandboxing capabilities shine: your users can extend the software you write, while you can rest easy knowing that these untrusted Wasm binaries run in a secure environment. This is the primary use case when your Wasm binaries are Extism plugins!
Now, while Java bytecode can normally be translated into Dalvik bytecode at build-time, this approach falls short if you want to load Wasm modules dynamically. The problem is that while most Java APIs for classloading and reflection work on Android, you cannot simply generate Java bytecode and load it into an Android class-loader, because that’s not the bytecode format Android expects.
Well, that’s alright—you might say—we can just translate the Java bytecode into Dalvik bytecode at run-time. If only! At the time of writing, there is no convenient tooling to perform that translation on-device.
There is, however, a bytecode engineering library called DexMaker. DexMaker’s main purpose is to allow you to generate Dalvik bytecode at run-time. The library is better known as a tool for generating dynamic proxies and as a dependency of Mockito for dynamically generating mocks.
So we thought: why not use DexMaker to generate Dalvik bytecode from Wasm at run-time?
DEX bytecode vs Java bytecode 🔗
The Dalvik bytecode format is a distant relative of Java bytecode, with one fundamental difference: Dalvik is register-based rather than stack-based. This means Dalvik instructions operate on registers instead of a stack of values, making the mapping between the two formats non-trivial.
In a modern Android toolchain, your build tool produces Java bytecode, which is then translated into Dalvik bytecode by the d8 tool from the Android SDK. The d8 bytecode translator follows a traditional multi-stage compiler architecture: it translates Java bytecode into an intermediate representation (IR), performs instruction selection and optimization, handles register allocation, and finally outputs Dalvik bytecode. DexMaker layers on top of d8, abstracting away these low-level details to provide a more streamlined API for generating Dalvik bytecode.
This means we need a separate Android backend for the Chicory compiler that works with register-based instructions. We can still reuse a lot of the JVM compiler code, but we have to watch out for the differences between the two approaches—especially with control-flow structures like branches and loops, where registers and stacks work pretty differently.
Consider this example:
int example() {
int x;
int param1 = 1;
int param2 = 2;
while (1) {
int sum = param1 + param2;
x = sum;
if (!(x < 10)) {
break;
}
// Prepare for next iteration
param1 = sum;
param2 = 3;
}
return x;
}
The equivalent Wasm code would look like this:
(func (export "example") (result i32)
(local $x i32)
(i32.const 1)
(i32.const 2)
(loop (param i32 i32) (result i32)
(i32.add)
(local.tee $x)
(i32.const 3)
(local.get $x)
(i32.const 10)
(i32.lt_u)
(br_if 0)
(drop)
)
)
The equivalent Java bytecode is relatively straightforward, because the JVM is also stack-based. The loop condition is checked at the end of the loop, and the parameters are updated at the end of each iteration.
// Method: func_0(Lcom/dylibso/chicory/runtime/Memory;Lcom/dylibso/chicory/runtime/Instance;)I
// Stack: 3, Locals: 3
0: iconst_0 // push 0 (initialize local variable)
1: istore 2 // x = 0 (local variable initialization)
2: iconst_1 // push 1 (loop param 1)
3: iconst_2 // push 2 (loop param 2)
// Loop start L0 - stack: [param1, param2]
4: iadd // add top two stack values -> stack: [sum]
5: dup // duplicate sum -> stack: [sum, sum]
6: istore 2 // store sum in local x -> stack: [sum]
7: iconst_3 // push 3 -> stack: [sum, 3]
8: iload 2 // load x -> stack: [sum, 3, x]
9: bipush 10 // push 10 -> stack: [sum, 3, x, 10]
10: invokestatic com/dylibso/chicory/runtime/OpcodeImpl.I32_LT_U (II)I // compare x < 10 -> stack: [sum, 3, result]
11: ifeq L1 // if result == 0 (false), exit loop -> stack: [sum, 3]
12: invokestatic com/dylibso/chicory/runtime/Memory.checkInterruption ()V // interruption check -> stack: [sum, 3]
13: goto L0 // loop back -> stack: [sum, 3] (these become new params)
// Loop exit L1 - stack: [sum, 3]
14: pop // remove the 3 -> stack: [sum]
15: ireturn // return sum
// Local variable table:
// 0: Memory parameter
// 1: Instance parameter
// 2: x (local variable)
A relatively direct Dalvik translation could pre-allocate the registers assigning them specific roles,
and ensure that they are preserved as invariants across iterations. In the following, the v0 register
is used to hold the loop result, v1 and v2 are the loop parameters, and v3 is the sum.
The loop condition checks if the sum is less than 10, and if so, it continues iterating.
;; ... function prologue (reads args etc) ...
0011: const/4 v1 #1 #1 ; param1 = 1
0012: const/4 v2 #2 #2 ; param2 = 2
0013: add-int v3, v1, v2 ; sum = param1 + param2
0015: move/from16 v0, v3 ; loop result = sum (allocated at loop header)
0017: const/16 v4 #3 #3 ; constant 3 (pushed to stack)
0019: move/from16 v5, v0 ; setup comparison operand 1
001b: const/16 v6 #10 #10 ; setup comparison operand 2
001d: invoke-static/range Lcom/dylibso/chicory/runtime/OpcodeImpl;->I32_LT_U(II)I {v5, v6} ; compare loop_result < 10
0020: move-result v7 ; branch condition result
0021: move/from16 v1, v3 ; param1 = sum (loop param update)
0023: move/from16 v2, v4 ; param2 = 3 (loop param update)
0025: move/from16 v0, v4 ; loop result = current stack top (systematic update)
0027: if-eqz v7 -> 002d ; if condition false, exit loop
0029: invoke-static Lcom/dylibso/chicory/experimental/android/aot/AotMethods;->checkInterruption()V {} ; runtime interruption check
002c: goto -> 0013 ; continue loop
002d: move/from16 v0, v3 ; loop result = final sum (systematic update)
;; ... function epilogue (return the values) ...
The loop result is consistently maintained in v0, which is allocated at the loop header (0011) and updated at each iteration (0025) and at the final exit (002d).
Notice how, at the end of the loop, we ensure that v0, v1 and v2 are updated with the latest values, so, as we re-enter the loop, the registers hold the correct values for the next iteration.
The main limitation of this approach is that it will waste a few registers, and generate a few more moves than strictly necessary. However this makes the compiler simpler: while more sophisticated approaches could be used to optimize the register usage, they could add overhead to the compiler and slow it down. We will revisit this in the future, but for now, we are happy with this approach.
Runtime Limitations 🔗
Even though nowadays Android devices can be pretty beefy, you cannot give resources for granted. In particular, to ensure a smooth user experience, the ART runtime poses some limitations on the amount of memory and stack space that can be used by an application. Let’s see what these limitations are, and how we can work around them.
Limitations on the Stack Size 🔗
Threads on the Dalvik runtime default to a stack size of 1 MB. This is a strict limit on the main thread, which is usually the one running the UIlogic. If you try to run a Wasm module that uses more than 1 MB of stack space, you will get a java.lang.StackOverflowError.
Add to that, that dynamically-loaded code is usually not pre-compiled to native code, and in fact, in most cases it will initially run in the Dalvik interpreter! This is not only a performance issue (that would be fine when we are only running tests): it also means that the stack usage is higher than it would be if the code was compiled to native code. For instance, this a snippet from the stacktrace of a recursive function:
--------- beginning of crash
F libc : Fatal signal 11 (SIGSEGV), code 2 (SEGV_ACCERR), fault addr 0x6ddb4fd000 in tid 27607 (roidJUnitRunner), pid 27566 (ndroid.aot.test)
E crash_dump64: failed to get the guest state header for thread 27566: Bad address
E crash_dump64: failed to get the guest state header for thread 27567: Bad address
...
I crash_dump64: obtaining output fd from tombstoned, type: kDebuggerdTombstoneProto
I tombstoned: received crash request for pid 27607
I crash_dump64: performing dump of process 27566 (target tid = 27607)
F DEBUG : *** *** *** *** *** *** *** *** *** *** *** *** *** *** *** ***
F DEBUG : Build fingerprint: 'google/sdk_gphone64_arm64/emu64a:15/AE3A.240806.043/12960925:userdebug/dev-keys'
F DEBUG : Revision: '0'
F DEBUG : ABI: 'arm64'
F DEBUG : Timestamp: 2025-07-11 11:18:25.911063122+0200
F DEBUG : Process uptime: 2s
F DEBUG : Cmdline: com.dylibso.chicory.android.aot.test
F DEBUG : pid: 27566, tid: 27607, name: roidJUnitRunner >>> com.dylibso.chicory.android.aot.test <<<
F DEBUG : uid: 10238
F DEBUG : tagged_addr_ctrl: 0000000000000001 (PR_TAGGED_ADDR_ENABLE)
F DEBUG : pac_enabled_keys: 000000000000000f (PR_PAC_APIAKEY, PR_PAC_APIBKEY, PR_PAC_APDAKEY, PR_PAC_APDBKEY)
F DEBUG : signal 11 (SIGSEGV), code 2 (SEGV_ACCERR), fault addr 0x0000006ddb4fd000
F DEBUG : x0 0000006ddb4faa80 x1 0000000000000000 x2 00000000000107a8 x3 0000006ddb4fd000
F DEBUG : x4 0000006ddb50d7e8 x5 0000000000000004 x6 0000006ddb50daf8 x7 0000006d5565be76
F DEBUG : x8 0000000000012d70 x9 0000006ddb50d7f0 x10 00000000000025a5 x11 0000006ddfb79040
F DEBUG : x12 0000006ddfb79040 x13 00000000000025a5 x14 0000006ddb50d7c8 x15 b400006fa33821b0
F DEBUG : x16 0000006de0224c10 x17 0000007082a97bc0 x18 0000006d528f8000 x19 b400006eb33a56a0
F DEBUG : x20 0000006ddb50db40 x21 0000006de040d000 x22 b400006f933820d0 x23 0000006ddb4faa80
F DEBUG : x24 0000006d00213840 x25 00000000000025a5 x26 0000000000012d28 x27 00000000000025a5
F DEBUG : x28 0000000000000003 x29 0000006ddb50d8d0
F DEBUG : lr 0000006ddfb5b774 sp 0000006ddb4faa80 pc 0000007082a97c84 pst 0000000020001000
F DEBUG : 512 total frames
F DEBUG : backtrace:
F DEBUG : #00 pc 0000000000055c84 /apex/com.android.runtime/lib64/bionic/libc.so (__memset_aarch64+196) (BuildId: 1b9fecf834d610f77e641f026ca7269b)
F DEBUG : #01 pc 000000000035b770 /apex/com.android.art/lib64/libart.so (bool art::interpreter::DoCall<false>(art::ArtMethod*, art::Thread*, art::ShadowFrame&, art::Instruction const*, unsigned short, bool, art::JValue*)+476) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #02 pc 000000000076da48 /apex/com.android.art/lib64/libart.so (void art::interpreter::ExecuteSwitchImplCpp<false>(art::interpreter::SwitchImplContext*)+12208) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #03 pc 000000000037b5d8 /apex/com.android.art/lib64/libart.so (ExecuteSwitchImplAsm+8) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #04 pc 00000000000004a8 [anon:dalvik-DEX data] (com.dylibso.chicory._gen.CompiledMachine_Chunk0.func_0+0)
...
F DEBUG : #69 pc 00000000000023b4 [anon:dalvik-DEX data] (com.dylibso.chicory._gen.CompiledMachine.call+0)
F DEBUG : #70 pc 000000000034e21c /apex/com.android.art/lib64/libart.so (art::interpreter::Execute(art::Thread*, art::CodeItemDataAccessor const&, art::ShadowFrame&, art::JValue, bool, bool) (.__uniq.112435418011751916792819755956732575238.llvm.2845697060370838518)+428) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #71 pc 000000000035c5b0 /apex/com.android.art/lib64/libart.so (bool art::interpreter::DoCall<false>(art::ArtMethod*, art::Thread*, art::ShadowFrame&, art::Instruction const*, unsigned short, bool, art::JValue*)+4124) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #72 pc 000000000076da48 /apex/com.android.art/lib64/libart.so (void art::interpreter::ExecuteSwitchImplCpp<false>(art::interpreter::SwitchImplContext*)+12208) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #73 pc 000000000037b5d8 /apex/com.android.art/lib64/libart.so (ExecuteSwitchImplAsm+8) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #74 pc 000000000000168c /data/app/~~mVADCp0l4u2tmGTofEPdqQ==/com.dylibso.chicory.android.aot.test-irCJzP1P57Ywof2WQebRvg==/base.apk (com.dylibso.chicory.experimental.android.aot.TestAotAndroidMachine.call+0)
F DEBUG : #75 pc 000000000034e21c /apex/com.android.art/lib64/libart.so (art::interpreter::Execute(art::Thread*, art::CodeItemDataAccessor const&, art::ShadowFrame&, art::JValue, bool, bool) (.__uniq.112435418011751916792819755956732575238.llvm.2845697060370838518)+428) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #76 pc 000000000035c5b0 /apex/com.android.art/lib64/libart.so (bool art::interpreter::DoCall<false>(art::ArtMethod*, art::Thread*, art::ShadowFrame&, art::Instruction const*, unsigned short, bool, art::JValue*)+4124) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #77 pc 000000000076da48 /apex/com.android.art/lib64/libart.so (void art::interpreter::ExecuteSwitchImplCpp<false>(art::interpreter::SwitchImplContext*)+12208) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #78 pc 000000000037b5d8 /apex/com.android.art/lib64/libart.so (ExecuteSwitchImplAsm+8) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #79 pc 000000000036a664 /data/app/~~mVADCp0l4u2tmGTofEPdqQ==/com.dylibso.chicory.android.aot.test-irCJzP1P57Ywof2WQebRvg==/base.apk (com.dylibso.chicory.runtime.Instance$Exports.lambda$function$0$com-dylibso-chicory-runtime-Instance$Exports+0)
F DEBUG : #80 pc 000000000034e21c /apex/com.android.art/lib64/libart.so (art::interpreter::Execute(art::Thread*, art::CodeItemDataAccessor const&, art::ShadowFrame&, art::JValue, bool, bool) (.__uniq.112435418011751916792819755956732575238.llvm.2845697060370838518)+428) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #81 pc 000000000035c5b0 /apex/com.android.art/lib64/libart.so (bool art::interpreter::DoCall<false>(art::ArtMethod*, art::Thread*, art::ShadowFrame&, art::Instruction const*, unsigned short, bool, art::JValue*)+4124) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #82 pc 000000000076da48 /apex/com.android.art/lib64/libart.so (void art::interpreter::ExecuteSwitchImplCpp<false>(art::interpreter::SwitchImplContext*)+12208) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #83 pc 000000000037b5d8 /apex/com.android.art/lib64/libart.so (ExecuteSwitchImplAsm+8) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #84 pc 000000000036a464 /data/app/~~mVADCp0l4u2tmGTofEPdqQ==/com.dylibso.chicory.android.aot.test-irCJzP1P57Ywof2WQebRvg==/base.apk (com.dylibso.chicory.runtime.Instance$Exports$$ExternalSyntheticLambda0.apply+0)
F DEBUG : #85 pc 000000000034e21c /apex/com.android.art/lib64/libart.so (art::interpreter::Execute(art::Thread*, art::CodeItemDataAccessor const&, art::ShadowFrame&, art::JValue, bool, bool) (.__uniq.112435418011751916792819755956732575238.llvm.2845697060370838518)+428) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #86 pc 000000000035c5b0 /apex/com.android.art/lib64/libart.so (bool art::interpreter::DoCall<false>(art::ArtMethod*, art::Thread*, art::ShadowFrame&, art::Instruction const*, unsigned short, bool, art::JValue*)+4124) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #87 pc 000000000076da48 /apex/com.android.art/lib64/libart.so (void art::interpreter::ExecuteSwitchImplCpp<false>(art::interpreter::SwitchImplContext*)+12208) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #88 pc 000000000037b5d8 /apex/com.android.art/lib64/libart.so (ExecuteSwitchImplAsm+8) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #89 pc 00000000002aa140 /data/app/~~mVADCp0l4u2tmGTofEPdqQ==/com.dylibso.chicory.android.aot.test-irCJzP1P57Ywof2WQebRvg==/base.apk (com.dylibso.chicory.test.gen.SpecV1FacTest.test1+0)
F DEBUG : #90 pc 000000000034d5a8 /apex/com.android.art/lib64/libart.so (artQuickToInterpreterBridge+1932) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #91 pc 0000000000379098 /apex/com.android.art/lib64/libart.so (art_quick_to_interpreter_bridge+88) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #92 pc 0000000000362774 /apex/com.android.art/lib64/libart.so (art_quick_invoke_stub+612) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #93 pc 000000000035e36c /apex/com.android.art/lib64/libart.so (_jobject* art::InvokeMethod<(art::PointerSize)8>(art::ScopedObjectAccessAlreadyRunnable const&, _jobject*, _jobject*, _jobject*, unsigned long)+540) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #94 pc 00000000006c87f8 /apex/com.android.art/lib64/libart.so (art::Method_invoke(_JNIEnv*, _jobject*, _jobject*, _jobjectArray*) (.__uniq.165753521025965369065708152063621506277)+32) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #95 pc 00000000001c8670 [anon_shmem:dalvik-jit-code-cache] (offset 0x2000000) (art_jni_trampoline+144)
F DEBUG : #96 pc 0000000000362774 /apex/com.android.art/lib64/libart.so (art_quick_invoke_stub+612) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #97 pc 000000000035bd1c /apex/com.android.art/lib64/libart.so (bool art::interpreter::DoCall<false>(art::ArtMethod*, art::Thread*, art::ShadowFrame&, art::Instruction const*, unsigned short, bool, art::JValue*)+1928) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #98 pc 000000000076da48 /apex/com.android.art/lib64/libart.so (void art::interpreter::ExecuteSwitchImplCpp<false>(art::interpreter::SwitchImplContext*)+12208) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #99 pc 000000000037b5d8 /apex/com.android.art/lib64/libart.so (ExecuteSwitchImplAsm+8) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
...
F DEBUG : #509 pc 00000000004b3d5c /data/app/~~mVADCp0l4u2tmGTofEPdqQ==/com.dylibso.chicory.android.aot.test-irCJzP1P57Ywof2WQebRvg==/base.apk (org.junit.runners.ParentRunner.access$100+0)
F DEBUG : #510 pc 000000000034e21c /apex/com.android.art/lib64/libart.so (art::interpreter::Execute(art::Thread*, art::CodeItemDataAccessor const&, art::ShadowFrame&, art::JValue, bool, bool) (.__uniq.112435418011751916792819755956732575238.llvm.2845697060370838518)+428) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
F DEBUG : #511 pc 000000000035c5b0 /apex/com.android.art/lib64/libart.so (bool art::interpreter::DoCall<false>(art::ArtMethod*, art::Thread*, art::ShadowFrame&, art::Instruction const*, unsigned short, bool, art::JValue*)+4124) (BuildId: dcb9fe2b5c99aa3f1a682a6008427d08)
E tombstoned: Tombstone written to: tombstone_31
I Zygote : Process 27566 exited due to signal 11 (Segmentation fault)
I adbd : Remote process closed the socket (on MSG_PEEK)
I libprocessgroup: Removed cgroup /sys/fs/cgroup/uid_10238/pid_27566
D InetDiagMessage: Destroyed 0 sockets, proto=IPPROTO_TCP, family=AF_INET, states=14
D InetDiagMessage: Destroyed 0 sockets, proto=IPPROTO_TCP, family=AF_INET6, states=14
D InetDiagMessage: Destroyed live tcp sockets for uids={10238} in 2ms
I app_process: System.exit called, status: 0
I AndroidRuntime: VM exiting with result code 0.
D InetDiagMessage: Destroyed 0 sockets, proto=IPPROTO_TCP, family=AF_INET, states=14
D InetDiagMessage: Destroyed 0 sockets, proto=IPPROTO_TCP, family=AF_INET6, states=14
D InetDiagMessage: Destroyed live tcp sockets for uids={20238} in 0ms
I netd : tetherGetStats() -> {[]} <0.34ms>
As you might notice from the stack trace above, for each guest function call, the Dalvik interpreter introduces 3 stack frames! That makes it quite easy to hit the stack overflow limit, especially if you are running a Wasm module that has a lot of nested function calls.
(art::interpreter::Execute(art::Thread*, art::CodeItemDataAccessor const&, art::ShadowFrame&, art::JValue, bool, bool)
(bool art::interpreter::DoCall<false>(art::ArtMethod*, art::Thread*, art::ShadowFrame&, art::Instruction const*, unsigned short, bool, art::JValue*)+4124)
(void art::interpreter::ExecuteSwitchImplCpp<false>(art::interpreter::SwitchImplContext*)+12208)
...
Now, even though this limit cannot be overcome on the main thread, you can still create a new thread with a custom stack size. This is generally the recommended way to run long computations on Android, as it allows you to avoid blocking the main thread and keep the UI responsive. The default stack size is still 1MB, but you can configure the stack size of a thread when you create it..
var stackSize = 8 * 1024 * 1024;
var t = new Thread(
new ThreadGroup("chicory-thread-group"),
myRunnable,
"chicory-thread",
stackSize);
There is still one big caveat; when you spawn a thread with a custom stack size, apparently you will get less guarantees from the Dalvik runtime. In particular, in our experiments, sometimes you might get a hard crash, instead of a managed StackOverflowError!
Fatal signal 11 (SIGSEGV), code 2 (SEGV_ACCERR), fault addr 0x7284415700 in tid 4791 (thread), pid 4754 (ndroid.aot.test)
Cmdline: com.dylibso.chicory.android.aot.test
pid: 4754, tid: 4791, name: thread >>> com.dylibso.chicory.android.aot.test <
#04 pc 00000000000004a8 /data/data/com.dylibso.chicory.android.aot.test/cache/chicory196337394512609375/com/dylibso/chicory/_gen/CompiledMachine_Chunk0/classes.dex (com.dylibso.chicory._gen.
#09 pc 00000000000004a8 /data/data/com.dylibso.chicory.android.aot.test/cache/chicory196337394512609375/com/dylibso/chicory/_gen/CompiledMachine_Chunk0/classes.dex (com.dylibso.chicory._gen.
#14 pc 00000000000004a8 /data/data/com.dylibso.chicory.android.aot.test/cache/chicory196337394512609375/com/dylibso/chicory/_gen/CompiledMachine_Chunk0/classes.dex (com.dylibso.chicory._gen.
#19 pc 00000000000004a8 /data/data/com.dylibso.chicory.android.aot.test/cache/chicory196337394512609375/com/dylibso/chicory/_gen/CompiledMachine_Chunk0/classes.dex (com.dylibso.chicory._gen.
#24 pc 00000000000004a8 /data/data/com.dylibso.chicory.android.aot.test/cache/chicory196337394512609375/com/dylibso/chicory/_gen/CompiledMachine_Chunk0/classes.dex (com.dylibso.chicory._gen.
#29 pc 00000000000004a8 /data/data/com.dylibso.chicory.android.aot.test/cache/chicory196337394512609375/com/dylibso/chicory/_gen/CompiledMachine_Chunk0/classes.dex (com.dylibso.chicory._gen.
#34 pc 00000000000004a8 /data/data/com.dylibso.chicory.android.aot.test/cache/chicory196337394512609375/com/dylibso/chicory/_gen/CompiledMachine_Chunk0/classes.dex (com.dylibso.chicory._gen.
// ... rest omitted ...
At this time we are not aware of a simple way to avoid this issue, but there is still a lot of work to do!
Memory Management 🔗
Finally, we managed to make all the spec tests pass on Android. Great, now let’s move onto some real-world Wasm modules! We started with the mcp.run fetch servlet, which is a Wasm module that fetches a webpage from a URL and returns it as Markdown. I was pretty bummed when ART started throwing a java.lang.OutOfMemoryError. Looking more closely, I noticed that the offender was the Chicory compiler itself, which was using more than 200MB of heap space!
Now, everybody knows that the JVM has limitations on class file size and method count. The Dalvik runtime has similar constraints, with a limit of 65535 methods per class file. So, on the JVM compiler, we generate multiple class files when the class file grows over 50k methods; if a function is too large, we just fall back to the interpreter. This works well on the JVM, but it is not enough on Android; it is mostly an issue related to the way DexMaker works. DexMaker retains the complete intermediate representation of all the generated methods in memory until the final DEX file is generated. This means that if you generate a lot of methods, the memory usage can grow significantly, especially if the methods are large.
Luckily, the solution is relatively straightforward: split class files at a lower boundary (currently 200 methods per “chunk”). This approach finally allowed us to “make fetch happen”!
Testing the Android backend 🔗
Android’s development tooling is not designed for this kind of lower-level work. Testing Android applications on device, typically uses the Android Instrumentation framework. The instrumentation framework is a powerful tool but comes with significant overhead; among other things, it transfers a lot of metadata between the host and the device. This is ok for end-to-end, integration testing, where flows are usually long and complex, but not so much for unit testing, where you want to run a lot of tests quickly.
Moreover, while the instrumentation framework is the default way to run tests on the device, most unit tests are usually run on the host machine on a plain JVM; even when Android-specific APIs are involved, Roboelectric simulates the Android environment, allowing you to run tests without the overhead of the instrumentation framework.
Unfortunately, none of this applies to our case: the JVM can’t load DEX bytecode, and the Chicory compiler must be tested on ART.
Some work has been done to run the test suite against the interpreter. Even though there is some overhead, it is manageable, because the interpreter can be tested and debugged on a traditional JVM. On Android we only ensure that there aren’t any platform-specific issues.
However, running the entire Wasm spec test suite against the Android compiler with the instrumentation framework takes about 8 minutes in Android Studio, and about 4 minutes using Gradle on the command line. This is not terrible, but it is still a lot of time to wait for a test suite to run, especially when you are iterating on the code. Compare this to the plain JVM, where the same test suite takes about **30 ** to run! (FIXME: the JVM number is made up, need to measure again)
So, I decided to investigate how to run unit tests on Android without the overhead of the instrumentation framework.
Running Plain Java on ART 🔗
Running unit tests on Android is not a common practice, but it is possible. Unfortunately documentation is scattered and a bit outdated, so we had to figure out a lot of things on our own. It doesn’t help that while some people still rever to the Android Java platform as the “Dalvik runtime”, Android has been using the Android Runtime (ART) since Android 5.0 (Lollipop), and that “ART” is a pretty unsearchable term. Moreover, even internally, the ART runtime is sometimes referred to as “Dalvik”, which adds to the confusion.
First of all, is it possible to run Java console applications on Android? It is; but first you have to figure out where the Java launcher is, and how to package your application.
In fact thanks to this lone Github repo we learn that the Java (ART) launcher is located at /apex/com.android.art/bin/dalvikvm64 (/apex/com.android.art/bin/dalvikvm is the 32-bit version). This is the launcher that you can use to run Java applications on Android.
Let’s write a simple Java application that prints the name of the host operating system to the console.
class Main {
public static void main(String... args) {
System.out.printf("Hello, %s %s\n",
System.getProperty("os.name"),
System.getProperty("os.version"));
}
}
On my machine, I can compile and run this code with the following commands:
❯ javac Main.java
❯ java Main
Hello, Mac OS X 15.5
Now, assuming your Android tools are on the PATH (on my machine they are in $HOME/Library/Android/sdk/build-tools/35.0.0), you can convert the class into a DEX file with the following command:
d8 Main.class
This will create a file called classes.dex in the current directory. This is the Dalvik bytecode that you can run on Android. Then, assuming you have a running Android emulator (or a connected device), you can upload the file to /tmp/main.dex with the following command:
❯ adb push classes.dex /tmp/main.dex
classes.dex: 1 file pushed, 0 skipped. 2.3 MB/s (1076 bytes in 0.000s)
Now you can run it on Android:
❯ adb shell /apex/com.android.art/bin/dalvikvm64 -cp /tmp/main.dex Main
Hello, Linux 6.6.30-android15-8-gdd9c02ccfe27-ab11987101-4k
Congratulations! You have just run a plain Java application on Android!
Running Unit Tests on Android 🔗
Putting it all together, assuming your android test cases are in androidTest you can run them with the following commands:
./gradlew assembleAndroidTest
adb push MY_PROJECT/build/outputs/apk/androidTest/debug/MY_PROJECT-debug-androidTest.apk /tmp/main.apk
adb shell /apex/com.android.art/bin/dalvikvm64 -cp /tmp/main.apk com.example.Main
for instance, if you are using junit4 you can start the launcher with the following command:
adb /apex/com.android.art/bin/dalvikvm64 -cp main.apk org.junit.runner.JUnitCore <test class>
This will run the JUnit test class on the Android device, and you will see the output in the console. Notice this is sidestepping the usual Android launcher. This means that you can run your tests without the overhead of the instrumentation framework, but also you will not be able to use any Android-specific features, such as the Android UI framework or other Android APIs. Just to give you an example, you will not be able to use the Android logging framework.
Running JUnit 5 tests on Android 🔗
Now, as an additional degree of complexity, the Chicory test suite uses JUnit 5, while the Android platform only supports JUnit 4 out of the box. There is an unofficial JUnit 5 Android support library that you can use; it also supports the Instrumentation Framework, and this is what we’ve been using so far.
But if you run from the console, you can just use the JUnit Platform Console Launcher, and add it to your dependencies; you will also need to ensure that is bundled in the APK: that means that all the dependencies mut be androidTestImplementation instead of androidTestRuntimeOnly!
androidTestImplementation("org.junit.jupiter:junit-jupiter-api:5.13.1")
androidTestImplementation("org.junit.jupiter:junit-jupiter-engine:5.13.1")
androidTestImplementation("org.junit.platform:junit-platform-console:1.13.1")
androidTestImplementation("org.junit.platform:junit-platform-suite:1.13.1")
It is also advisable to create a Suite and list all the classes you want to run, as classpath scanning will not work. In our case:
package com.dylibso.chicory.test.gen;
import org.junit.platform.suite.api.*;
@SelectClasses({
SpecV1AddressTest.class,
SpecV1AlignTest.class,
...
SpecV1Utf8ImportModuleTest.class,
SpecV1Utf8InvalidEncodingTest.class,
})
@Suite
public class SpecV1 {}
Then once built and uploaded to /tmp/main.apk:
./gradlew assembleAndroidTest
adb push MY_PROJECT/build/outputs/apk/androidTest/debug/MY_PROJECT-debug-androidTest.apk /tmp/main.apk
adb shell /apex/com.android.art/bin/dalvikvm64 -cp /tmp/main.apk com.example.Main
you will finally be able to run the tests with the following command:
adb shell /apex/com.android.art/bin/dalvikvm64 -cp /tmp/main.apk org.junit.platform.console.ConsoleLauncher -c com.dylibso.chicory.test.gen.SpecV1
The boot might take a little time: you can follow on logcat if you are bored, and you’ll see that something is indeed happening; eventually you will see the test results in the console!
This finally brings the test time down to about 14 seconds, which is a lot more manageable than the 8 minutes we had before!
The Hard Way: Running Tests with a Custom Launcher 🔗
Can we bring this down further? After all, the spec test suite is generated code, we know exactly what it does, and we could run it without the JUnit framework. With this custom launcher, we can write a simple Main class that runs the tests directly, without the JUnit framework:
public static void main(String... args) throws Exception {
var tests = Class[] {
SpecV1AddressTest.class,
SpecV1AlignTest.class,
// ... all the other test classes ...
SpecV1Utf8ImportModuleTest.class,
SpecV1Utf8InvalidEncodingTest.class,
};
var runner = new SpecTestRunnerMain(8 * 1024 * 1024, tests);
runner.runSuiteOnThread();
}
The entire suite runs now in about 6 seconds on the Android device.
Debugging the Android backend 🔗
It is also possible to attach a debugger to the Android process running the tests. This is useful to debug the Chicory compiler and the generated Dalvik bytecode. In this case, the instructions are even more hard to find, but with some trial and error, especially following the logcat output I was able to figure out that you can attach a debugger to the Android process running the tests by using the following command:
/apex/com.android.art/bin/dalvikvm64 -Xplugin:libopenjdkjvmti.so -agentpath:libjdwp.so=server=y,suspend=y,transport=dt_socket,address=0.0.0.0:8000 -cp /tmp/main.apk com.example.Main
Then you will be able to attach a remote debugging session using your favorite IDE (e.g. IntelliJ IDEA or Android Studio) to the port 8000 on the Android device.
The critical part is -Xplugin:libopenjdkjvmti.so, otherwise the -agentpath flag has no effect.
Conclusion 🔗
The Android backend of the Chicory compiler is still a work in progress, but it is showing promising results. If you are interested in lower-level Android development, or if you want to run Wasm modules on Android, I hope this article has given you some insights into the challenges and solutions we have found so far. If you want to try it out follow the instruction on the [https://github.com/dylibso/chicory-compiler-android][chicory-compiler-android] repository. The Android backend is still experimental, but you can already try it with the Chicory SDK and the mcpx4j library. Feel free to open issues if you find any problems or have suggestions for improvements.
